Engineering Design Graphics with Autodesk Inventor 2027

Description

Go beyond CAD basics with Autodesk Inventor 2027 training that connects design skills to real engineering applications.

Using a clear, step-by-step format, Engineering Design Graphics with Autodesk Inventor 2027 shows students how to create and document designs in Autodesk Inventor. Chapter test questions, sample problems, end-of-chapter projects, and additional exercises reinforce key concepts and give students hands-on practice. Going beyond typical CAD instruction, the book also includes exercises that challenge students to design simple mechanisms, helping connect software skills with practical engineering design and problem-solving. This book includes the following features:

• Updated for Autodesk Inventor 2027, with coverage aligned to the latest software features.
• Step-by-step instruction helps students work directly from the text to the screen and provides a useful reference during and after the course.
• Comprehensive coverage spans two-dimensional sketching, 3D models, assemblies, and detailed drawing generation.
• Chapter tests, sample problems, end-of-chapter projects, and additional exercises support self-assessment and hands-on practice.
• Mechanism-design exercises encourage students to apply Inventor skills to realistic engineering problems.
• ANSI and ISO standards are discussed where appropriate, introducing students to relevant techniques and national standards.

Sample Content

Table of Contents

Chapter 1 Get Started

Chapter 2 Two-Dimensional Sketching

Chapter 3 3D Models

Chapter 4 Orthographic Views

Chapter 5 Assembly Drawings

Chapter 6 Threads and Fasteners

Chapter 7 Dimensioning a Drawing

Chapter 8 Tolerancing

Chapter 9 Springs

Chapter 10 Shafts

Chapter 11 Bearings

Chapter 12 Gears

Chapter 13 Sheet Metal Drawings

Chapter 14 Weldment Drawings

Chapter 15 Cams

Chapter 16 Projects (Online Only)

Appendix Standards and Reference Tables
